Double Action Baler Top Ejection

  • Home
  • Double Action Baler Top Ejection
DOUBLE ACTION BALER AUTO DOOR 3 jpg 1

Offering Advanced Solution for Scrap: Double Compression Top Ejection

Double Compression Top Ejection metal scrap baling press machine primarily compresses light scrap metal such as waste cans and tins, stainless steel scrap, copper scrap, several metal shavings, waste aluminum profiles, aluminum chips, non-ferrous and ferrous metal scrap, and so on…
Our Double Compression Top Ejection metal scrap baling press machine is mainly used in steel manufacturers and many waste disposal recycling centers. This equipment is composed of three sections: hydraulic system, electrical system, mainframe, automatic PLC control, or manual control, which is a more optional choice for you. It can compress many materials such as metal scrap, aluminum scrap, stainless scrap, copper scrap, all kinds of ferrous and non-ferrous metals, and more.

Request a Quote
LOOKING FOR Bailing Machineries Manufacturers, Suppliers

A Technology For Recycle

Contact Us

telephoneCall Now: +91-98253-60680

MASK Hydraulic Machineries logo w

Working Principle of Double Compression Top Ejection

The metal scrap is placed into the box chamber using a grabber or other tools. Then, the lid of the baler machine is closed, and the main cylinder presses the scrap metal to the limit of the side cylinder. Then, the locking door cylinder begins to raise the door to the limit of the waste can and tin baling press machine. The ejector cylinder then uplifts the bale upward. At last, each cylinder returns to its starting position, completing the bale cycle.

View All Products
DOUBLE ACTION BALER AUTO DOOR 1jpg 4
DOUBLE ACTION BALER AUTO DOOR 2jpg 4

Applications of Double Compression Top Ejection

Advantages of Double Compression Top Ejection Metal Scrap Baling Press

DOUBLE ACTION BALER AUTO DOOR 3 jpg 1
1. This baler machine adopts a Top Ejection System.
2. It is simple to operate and maintain, saving stock and labor costs, transportation costs, and space.
3. Automatic PLC control with remote and manual control, two methods of control for your convenience, easy to use and maintain.
4.The inner wear plate adopts a well-known international brand of NM450 that is both durable and trustworthy, and Hardox450 is optional.
5.Output capacity ranges from 500 to 5000 kg per hour, giving you more alternatives.
6.Bale size and weight can be modified to meet your specific needs.
7.Uses German Hydraulic technology to ensure the equipment runs smoothly and consistently.
8.Adopts an international well-known brand of hydraulic pump and valves, to enhance the service life of the baler machine.
9.It's an ideal choice for your business as it is very affordable and economical.

Parameters

Model Box Size (INCH) Bale Size (INCH) Bale Weight (KG) Power (HP)
ECONOMY 5 X 15 45X15X12 5 X 15 15-20 15
ECONOMY 6 X 15 45X15X13 6 X 15 20-25 15
ECONOMY 8 X 15 45X15X15 8 X 15 20-25 15
ECONOMY 10 X 15 45X15X17 10 X 15 25-30 15
ECONOMY 12 X 15 45X15X18 12 X 15 30-35 15
ECONOMY 12 X 18 45X18X20 12 X 18 35-40 15
ECONOMY 18 X 18 50X18X26 18 X 18 50-55 20
ECONOMY 20 X 20 50X20X28 20 X 20 60-65 20
ECONOMY 12 X 24 50X24X20 12 X 24 60-65 20
ECONOMY 16 X 24 50X24X24 16 X 24 65-70 20
ECONOMY 18 X 24 60X24X22 18 X 24 70-75 20
